Vehicle Road Speed Sensor

Vehicle Road Speed Sensor

Aftermarket
SKU:
WSDSS1
Availability:
Usually ships within 3-4 business days
$125.00
(No reviews yet)
Current Stock:
Adding to cart… The item has been added
Description

The Road Speed sensor is required for all 14CUX and GEMS installation, and is required for proper operation of the idle control software. This is also known as a Vehicle Speed Sensor (VSS). Failure to provide the signal will cause the vehicle to stall every time you pull up, especially with a manual transmission.

If your vehicle has no speedo at all (some competition vehicles), then it is possible to use a simple proximity sensor to pick up the driveshaft bolts as they go by. This sensor and diagram will help you achieve this.

  • built in LED indicator light for setup
  • Triggered by ferrous material (Not magnets)
  • M12 body
  • Stainless steel body
  • Detection range 0.1MM to 1MM
  • Flush mount
  • Supply voltage 10V-30V
  • Short circuited/reverse protection built in.
  • Working temperature -13F to 176F
  • IP67 rated (water proof)
  • Normally open signal
  • Max switching frequency 8,000HZ



wiring:

Brown = power supply (10-30VDC)

Blue = Clean ground

Black = Signal wire  (Outputs 0V) to data logger.
