iCarsoft LR V2.0 Multi-System ECU Scan Tool For Land Rovers And Range Rovers

Product Details

iCarsoft LR V2.0 is a powerful vehicle fault diagnosis tool. With a 4 inch TFT LCD screen and unique diagnostic software, this powerful tool features full ECU diagnosis for CANBUS, ISO9141, KWP2000, and more. This tool will enable technicians and DIYers to accurately diagnose complex problems with their Rover.

Product Features

• iCarsoft LR V2.0 can do it all-reads and clears trouble codes on most of the systems such as engine, transmission, ABS and airbag etc.
• Support OBDII/EOBD Ten Modes of Operation
• Read Live Data
• Full ECU Diagnosis
• Applies to the single Brand of most of the Models which equipped with OBDII-16 DLC
• Easy To Use With Silicone Keys
• Oil Light/Service Reset: Support service lamp reset.
• Electronic Parking Brake (EPB) system maintenance deactivates and reactivates the EPB system for replacement and initialization.
• Battery Management System (BMS), registers new battery to the BMS while battery replacement.
• Diesel Particulate Filter (DPF) regeneration control system, requests the DPF regeneration process while DPF blockage and turn off the DPF indicator.
• Electronic Throttle Control system (ETC) relearns the throttle value while clear or replaces the throttle valve.
• SAS: Steering Angle Sensor (SAS) calibration, calibrates the steering wheel to straight ahead or recalibrates SAS while steering part replacement.
• The Print Data function allows you printing out diagnostic data recorded by the scan tool or customized test reports.
• Battery test allows you getting the voltage of battery with OBD port by the scan tool when the engine starts.
• DTC Library to lookup when user is operating this tool.
• Upgrade Via PC
• Multi-language: English, German, Dutch, Spanish, French.

15 Super Advantages:

• Diagnose Single Brand of most Models
• Full System Diagnosis
• Support Oil Service Reset
• Electronic Parking Brake (EPB) System Maintenance
• Battery Management System (BMS)
• Diesel Particulate Filter (DPF) Regeneration Control System
• Electronic Throttle Control System (ETC)
• Steering Angle Sensor (SAS) Calibration
• Read And Clear DTCs
• Read Live Data
• Support Battery Test
• Support Data Review And Print
• Full Speed Upgrade via PC
• 4 inch TFT LCD, 480x320 Pixels
• Supports Multiple Languages

OBDII Functions

• Read Codes
• Erase Codes
• I/M Readiness -- I/M Readiness indicate whether or not the various emissions-related systems on the vehicle are operating properly and are ready for Inspection and Maintenance testing
• Data stream
• Freeze Frame -- When an emission-related fault occurs, certain vehicle conditions are recorded by the onboard computer. This information is referred to as freeze frame data. Freeze Data is a snapshot of the operating conditions at the time of an emission-related fault.
• O2 Sensor Test -- This option allows retrieval and viewing of O2 sensor test results for most recently performed tests from the vehicle's onboard computer.
• On-Board Monitoring -- This function can be utilized to read the results of on-board diagnostic monitoring tests for specific components/systems.
• Evap System Test -- The EVAP test function lets you initiate a leak test for the vehicle's EVAP system. Before using the system test function, refer to the vehicle's service repair manual to determine the procedures necessary to stop the test.
• Vehicle Information -- The option displays the vehicle identification number (VIN), the calibration verification number (CVN), and other information of the test vehicle.
• Retrieve generic (P0, P2, P3, and U0), manufacturer specific (P1,P3, and U1) codes and pending codes
• Turn off Check Engine Light (MIL), clear codes and reset monitors
• Read live PCM Data Stream
• Supports CAN (Controller Area Network)
• Multilingual menu and DTC definitions English, Spanish, and German, etc.
• Read pending DTCs
• Read permanent DTCs
• DTCs search
• Supports most of the OBDII/EOBD test modes include: CAN, ISO9141, KWP2000, J1850 VPW and J1850 PWM.
• Works on most of 2001 and later OBDII compliant PETROL European vehicles
• Works on most of 2004 and later OBDII compliant DIESEL European vehicles
• Works on most of 1996 and later OBDII compliant US and Asian vehicles
• View & Graph Live Data in Color Graphing and blazing fast refresh rate for better graphing and live data readings.
• Comprehensive Help, Including OBD Parameter, Mode Explanations & More.

• Fits

  • All Land Rovers
